Professional manufacturer of automatic measuring packaging machine

KFS-514-C

Home Products KFS-5 Series KFS-514-C

Introduction

KFS-514-C

Microcomputer vertical small conveying cup mixing automatic metering packaging machine

  • Four-side seal.
  • Semi-automatic manual feeding and metering.
  • The packaging machine adopts PLC control system, adopts man-machine interface touch mode.
  • When there is no paper or material, and the electric heating fails, it will stop automatically with a buzzer.
  • The PLC panel can set the packaging quantity and automatic counting function
  • Need to bring your own air compressor 3HP for use
  • With electric eye device, automatically track the electric eye point of the packaging bag
  • Product style: back seal ※Only for a single specification
  • Product size: L: 50-230mm W: 50-140mm
  • White iron platform: iron body, shell covered with white iron SUS304 stainless steel.
  • Painting table: The body is made of cast iron, and the contact surface with the product is SUS304 stainless steel.

  • Basic equipment: 1 set of toolbox, 1 electric heating tube, 1 electric heating rod, instruction manual.

HCP Series

  • Packaging machine adopts PLC control system, adopts man-machine interface touch mode
  • No paper, no material, automatic buzzer shutdown when electric heating fails
  • The number of packages can be set, and the automatic counting function
  • With electric eye device, automatically track the electric eye point of the packaging bag

    • ※This series is optional, you can choose according to your needs

Applications
Specification

  • Applicable packaging

    Mixed packaging of a variety of different packaging materials, such as mixed packaging of hardware supplies, screws, dried vegetables, tea leaves, candies, granule seasonings, etc., can be automatic or semi-automatic.

  • Applicable packaging materials

    CPP, OPP, PET+PE, aluminum foil, heat-sealed composite multi-layer film material.
Mechanical Type Basic Product Style
Mechanical Model KFS-514-C
Product Style Four sides cover
Mechanical Weight 350KG
Motor Power Servo Motor 400W Main Motor
Mechanical Power 220V single phase
Mechanical Speed 35-55 packs/min depending on the package
Mechanical Dimensions L1000*W910*H1500MM
Heater Power 350W X 2PCS 300X 2PCS

KFS-533-R

Microcomputer Control For Triangle Type With Cup Volumetric Automatically Packing Machine For Flowing Powder Particle And Grains Granules.

KFS-533

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal For Triangle Type Automatically Packing Machine.

KFS-514-R

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Cup Volumetric Automatically Packing Machine.

KFS-514-L

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Piston Filling Type Automatically Packing Machine For Liquid Filling.

KFS-514

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal Automatically Packing Machine.

KFS-513-R

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Cup Volumetric Automatically Packing Machine.

KFS-513-L

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Piston Filling Type Automatically Packing Machine For Liquid Filling.

KFS-513-C

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Bucket Conveyor Automatically Packing Machine For Mixed Seasoning Or Hardware.

KFS-513

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal Automatically Packing Machine.

KFS-511-R

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Cup Volumetric Automatically Packing Machine.

KFS-511-L

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Piston Filling Type Automatically Packing Machine For Liquid Filling.

KFS-511-C

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal With Bucket Conveyor Automatically Packing Machine For Mixed Seasoning Or Hardware

KFS-511

Microcomputer Control Type Of Air-action Intermitten System Form-fill-seal Automatically Packing Machine.
